Set of bearings for transport roller 25

CAD download

PDF data sheet

3D view

Set of bearings for transport roller 25

210894/0
Detailed description
Price: 2,60 € (3,17 € incl. VAT)
In stock in the central warehouse.
Delivery 2-4 weeks.
Add to the cart
Shipping costs
You have additional questions about this product?
Add to the popular

You can add to the product:

Technical data/items supplied

  • Bearing bushing, PA 6
  • Axle bolt, steel
  • Roller carrier, ABS grey
  • For conveyor rollers from 60 - 1000 mm
  • Load/roller max. 20 kg
  • Weight = 0.044 kg/piece

Applications

  • Roller tracks of unlimited length
  • Drive via round belt Ø 5 mm possible
  • The following is needed to make a conveyor roller:
    2x bearing set, ABS
    1x tube ABS, aluminium or stainless steel with appropriate length
    (For tube lengths, see Part no. 210890/0 or 210892/0)

Assembly

  • Assembly of the roller carrier on all profiles of profile series 45 possible
  • Press bearing bush into the tube
    (deburr the inside of the tube generously for improved assembly)
  • Insert axle bolt in bearing bush
  • Place roller carrier on axle and insert in profile groove
  • For axial securing of the roller carriers, we recommend fixing the T-slot bars or square nuts in the profile groove with setscrews or close off the profile end with an end cap AL
